TYPE |
1 Section / 8 Panel |
4 Section / 8 Panal |
4 Section / 12 Panal |
MOUNT TYPE |
Fixed |
Fixed |
Fixed |
FEED TYPE |
Prime focus quard and feed support |
Prime focus quard and feed support |
Prime focus quard support |
DIAMETER (D) |
149.5 cm |
160 cm |
185 cm |
DEPTH (H) |
26.8 cm |
29 cm |
32 cm |
FOCAL LENGTH (F) |
52.1 cm |
57.1 cm |
66.8 cm |
F/D RATIO |
0.35 |
0.34 |
0.36 |
STANDPOLE LENGTH |
78 cm. |
78 cm |
97 cm |
STANDPOLE DIAMETER |
4.2 cm. |
4.2 cm |
5.8 cm |
FEED LENGTH |
76.3 cm |
76.3 cm |
97.2 cm |
OPERATINF FREQUENCY |
3.20 – 12.75 GHz |
3.20 – 12.75 GHz |
3.20 – 12.75 GHz |
C-BAND GAIN |
34.18 dBi |
43.63 dBi |
36.0 dBi |
KU-BAND GAIN |
43.65 dBi |
43.63 dBi |
45.5 dBi |
FINISH |
Electrostatic powder coat |
Electrostatic powder coat |
Electrostatic powder coat |
NET WEIGHT |
2.2 kg. (only dish) |
2.66 kg. (only dish) |
3.8 kg. (only dish) |
